Judgment

Parameter Introduction

Calculation Parameters

Parameter	Range	Default Value	Description	Diagram
Type	Number/String/Bool	Number	Select the data type of the variable to be judged
Target xxx	-	-	The variable to be judged; can be bound
Expected xxx	-	0.000	The expected value of the bound variable
Deviation (-)	-	0.000	Negative tolerance of the expected value. If the target value is outside the tolerance range, the judgment result is NG
Deviation (+)	-	0.000	Positive tolerance of the expected value. If the target value is outside the tolerance range, the judgment result is NG
Deviation Warning (Enable)	true/false	false	When enabled, the Warning range can be set
Deviation Warning (-)	-	0.000	Negative tolerance of the warning value. If the target value is outside the tolerance range, the judgment result is Warning
Deviation Warning (+)	-	0.000	Positive tolerance of the warning value. If the target value is outside the tolerance range, the judgment result is Warning

Troubleshooting

No.	Error Message	Corresponding Parameter	Solution
1	Input data does not match expected data	Expected Value / Deviation	The target value is outside the deviation range; modify the expected value or deviation value to an appropriate one.
2	Unknown type "xxx"	Type	Select one type from Number/String/Bool.
